Spec Item

Description

CPU Cooler

CPU Cooler

Heat Spreader

Display

Display

Dual display supported

VGA (up to 1920x1200@60Hz)

(Due to Intel GMA driver limitation, the monitor connected to the VGA connector may not have signal to it or become extended desktop after restarting from the graphics driver installation. To solve this problem, press the Ctrl+Alt+F1 hotkey to switch the primary screen to CRT mode.)

24-bit single-channel LVDS1 (D2550) (up to 1440x900@60Hz)

18-bit single-channel LVDS1 (N2600/N2800) (up to 1366x768@60Hz)

24-bit dual-channel LVD2 (up to 1920x1200 (D2550) or 1600x1200 (N2600/N2800)@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C with free air, -20°C ~ 70°C with force air for D2550 processor

-20°C ~ 70°C with free air, -20°C ~ 75°C with force air for N2600 processor

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot (support mSATA)

1 x Half-size PCIe Mini card slot

I/O Interface

Audio

Realtek ALC662 HD Audio codec

Digital I/O

8-bit digital I/O (4-bit input / 4-bit output)

Ethernet

Dual LAN: Realtek RTL8111E controllers

I/O Interface

5x RS-232

1 x RS-422/485

4 x USB2.0

1 x 6-pin wafer for PS/2 KB/MS

I/O Interface

I/O Interface

3 x RS-232

1 x RS-422/485

6 x USB 2.0

Power

Power consumption

[email protected] (1.86GHz Intel® D2550 with 1 GB DDR3 1066 MHz)

[email protected] (1.6GHz Intel® N2600 with 1 GB DDR3 1066 MHz)

Storage

Storage

2 x SATA 3Gb/s

1 x mSATA(colay SATA2)

System

Chipset

Intel® NM10

CPU

Intel® dual core Atom? D2550 1.86GHz processor

Intel® dual core Atom? N2600 1.6GHz processor

Intel® dual core Atom? N2800 1.86GHz processor (optional)

PU Socket

On board

Memory Max.

One 204-pin 1066 MHz DDR3 SDRAM SO-DIMM slot supports up to 4 GB (D2550/N2800) or 2 GB (N2600)

Watchdog Timer

Watchdog Timer

Software programmable and supports 1~255 sec. system reset
